Equipment Characteristics
Ultra long contact length ensures high traction even with low friction coefficient between pipe and belt/rubber blocks.
The down caterpillars can be set mechanically/electrically to the pipe position, and the upper caterpillars/rubber blocks arepressed onto the pipe pneumatically.
Each caterpillar is driven by a separate induction motor. Achieving synchronization control through the digital controller, can ensure that speed of all caterpillars is precisely synchronized.
The haul-off with three caterpillars and above is equipped with the imported LENZE motor. The belt haul-off is equipped with NORD motor.
The imported encoder is adopted to form a closed-loop control and guarantee more stable and reliable speed.
Large color touch screen, alarm status displayand alarm light prompt for easy maintenance.
Technical parameter
| Model | H32 | H63 | H160-3 | H250-4 | H315-4 | H450-4 | H630-6 | H800-6 | H1200-10 | H1600-12 | H2000-12 |
| Contact length | 1000 | 1200 | 1600 | 1600 | 1600 | 1600 | 1600 | 1600 | 2400 | 2400 | 2400 |
| Pipe range | 4-32 | 10-63 | 20-160 | 50-250 | 75-315 | 90-450 | 200-630 | 315-800 | 630-1200 | 710-1600 | 1000-2000 |
| Max. hauling speed | 1-80 | 1-45 | 0.5-20 | 0.2-10 | 0.1-5 | 0.1-2.2 | 0.05-1.25 | 0.03-0.8 | 0.01-0.5 | 0.01-0.17 | 0.01-0.12 |
